PCB業界に12年間携わってきたPCBWayは、世界でPCBプロトタイピングおよび少量生産の大手サプライヤの1つとして誇りを持っています。 Gerberファイルが当社のエンジニアによって審査および承認されてから24時間以内であれば、作業時間を大幅に短縮できます。
仕事の時間枠がそれほど厳しくない場合は、予算に合わせて他のタイムスケジュールを選択することもできます。 我々は、48時間と72時間の輸送も提供します。
配達が早いことが品質に妥協することはありません。 私達の厳格なテスト手順で、あなたはあなたがあなたのハイテク仕事のために私達のPCBに満足することを保証することができます。 品質以外にも、他のすべての製造業者が価格を上回っている可能性があります。これは、研究と設計を完成させるために何千ものPCBが必要になる可能性があるためです。 あなたがより低い価格を提供する他の製作者を見つけるならば、どうぞ我々に知らせてください、そして、我々は彼らを倒します！
当社のオンラインインスタント見積システムを試して、当社のPCBがどれほど競争力があるかを知らせてください。 今すぐ始めましょう。
| PCB Order Quantity (m2) | Original Lead Time (Days) | Current Lead Time (Hours) |
|---|---|---|
| 0- 50 pcs & < 1m2 | 2 - 3 Days | 24 Hours |
| 1m2 - 5m2 | 5 - 6 Days | 3 - 4 Days |
| 5m2 - 10m2 | 6 - 7 Days |
4 - 5 Days |
| More than 10m2 | 8 - 10 Days |
5 - 6 Days |
|
We shorten the delivery time while guarantee quality，produced by chemical processes for pads and vias metallization,Refuse conductive adhesive technology to save costs ,each order must go through 70 minutes copper plating，AOI and probe test,and we take advantage of internationally known base materials. In addition to the reduction in lead time, PCBWay not only reduced the price of small batch PCB,but also the freight cost for DHL parcels below 1 KG. |
||
| Layers | PCB Order Quantity (m2) | Build Time (Days) | Extra Urgent (Hours) |
|---|---|---|---|
| 2 Layers | <1 m2 | 5 Days | 48 Hours |
| 1-5 m2 | 7 Days | ||
| >5 m2 | 8 Days | ||
| 4 Layers | <1 m2 | 5 Days | 48 Hours |
| 1-5 m2 | 7 Days | ||
| >5 m2 | 12 Days | ||
| 6 Layers / 8 Layers | <1 m2 | 7 Days | 72 Hours |
| 1-5 m2 | 9 Days | ||
| >5 m2 | 12 Days | ||
| 10 Layers | <1 m2 | 10 Days | 96 Hours |
| 1-5 m2 | 10 Days | ||
| >5 m2 | 15 Days | ||
| 10 or more Layers | <1 m2 | 10 Days | 96 Hours |
| 1-5 m2 | 10 Days | ||
| >5 m2 | 15 Days | ||
|
Advanced PCBs are commonly used in high-precision electronic devices.With the continuous development of technology, the demand is also getting higher and higher. To this end, the separate advanced PCB production workshop is opened to assist our customers achieve the best possible time to market and competitive advantage by producing PCBs in a sustainable way at the lowest total price through our fabrication capabilities, delivery punctuality and product quality. Proven Technology Professional R&D on high density HDI, multi-layer PCB, rigid-flex PCB. Embedding technology of small size core, thick GEM, PCB with special requirements from industries like Telecom / medical / automotive, and etc. Qualified Materials Sourcing high quality materials from Rogers, Shengyi, Wazam, Dupont, Rohmhass, Atotech and other excellent suppliers to choose the best ones. Independent Production Line When you order advanced PCBs from PCBWay, you are buying quality that pays for itself over time. In the comparison chart below you can see where the advanced PCB is unique or goes beyond the IPC standard. |
|||
